Description
Description
The tote lifter is designed to lift open bottom skids, boxes, and baskets. Lifter is DC power with rocker switch to raise or lower. This DC powered unit includes an on-board battery charger. The side stabilizers lock lift in place when load is raised over a certain height.
Features
- Solid steel construction provides long lasting rugged use
- Automatic stabilizers engage when forks reach specific height
- Stabilizers design prevent unit from moving
- Front rollers and two rear swivel casters allow for easy portability
Specifications
| Specification | Details |
|---|---|
| Assembly Required | None |
| Color / Finish | Blue |
| Frame Material | Steel |
| Fully Welded Frame | Yes |
| Handle Length (in) | 30 |
| Handle Material | Steel / Composite |
| Material | Steel |
| Lift Height Maximum | 31.5 |
| Maximum Travel Distance (in) | 28 |
| Maximum Amperage (A) | 140 |
| Power Source | Electric |
| Voltage (V) | 12 |
| Weight Capacity (lbs) | 3000 |
| Maximum Fork Height (in) | 31.5 |
| Depth (in) | 63 |
| Height (in) | 46.5 |
| Width (in) | 26.75 |
| Wheel Material | Poly on Steel |
| Fork Lowered Height (in) | 3.5 |
| Fork Width (in) | 27 |
| Fork Length (in) | 45 |
Documents
Warranty
- Does this Product Have a Warranty?: Yes
- Manufacturer Warranty: 1 Year
- Warranty Type: Limited - Parts
- Manufacturer Warranty #2: 90 Days
- Warranty Type #2: Wearable Parts warranty
