Description
Description
Sturdy and compact to fit through standard doors. Forks are raised by manual hydraulic hand pump operation and released by a lever situated on the handle. 1" lift per handle pump. Two rigid and two swivel wheels standard.
Features
- Narrow mast to fit in compact areas
- Unique construction is maintenance free and easy to use
- Full height push handle allows for easy steering
- Hand pump design offers easier and safer lifting
Specifications
| Specification | Detail |
|---|---|
| Power Source | Electric - Cordless |
| Maximum Lift Height (in) | 59 |
| Minimum Lift Height (in) | 1.5625 |
| Maximum Travel Distance (in) | 57.4375 |
| Weight Capacity (lbs) | 770 |
| Color / Finish | Black/Yellow |
| Frame Material | Steel |
| Fork Length (in) | 29.9375 |
| Fork Width (in) | 3.125 |
| Adjustable Forks | Yes |
| Minimum Width Between Forks (in) | 6 |
| Maximum Width Between Forks (in) | 24 |
| Adjustable Legs | Yes |
| Leg Width (in) | 4 |
| Minimum Width Between Legs (in) | 35.5 |
| Maximum Width Between Legs (in) | 47.25 |
| Battery Charger Included | Yes |
| Horsepower (hp) | 0.5 |
| Phase | Single Phase |
| Voltage (V) | 12 |
| Number of Casters / Wheels | 4 |
| Rear Wheel Diameter (in) | 6 |
| Rear Wheel Material | Phenolic |
| Front Wheel Diameter (in) | 4 |
| Front Wheel Material | Phenolic |
| Weight (lbs) | 492 |
| Manufacturer Warranty | 1 Year |
Documents
Warranty
- Does this Product Have a Warranty?: Yes
- Manufacturer Warranty: 1 Year
- Warranty Type: Limited - Parts
- Manufacturer Warranty #2: 90 Days
- Warranty Type #2: Wearable Parts warranty
